Thermally Conductive Silicone Grease Mil-Spec High Heat Transfer System Industrial Military Grade

Thermo-Grease 04 is an opaque white heat sink grease compound, which is applied to the base and mounting studs of transistor and diodes to provide a positive heat sink seal, this facilitates heat transfer away from electrical/electronic components and into heat sinks, thereby increasing the overall efficiency and performance of the device. GR104 is grease like silicone material, heavily filled with efficient heat conductive zinc oxide and a binding agent, this combination promotes high thermal conductivity, high temperature stability, and the lowest amount of bleed and evaporation. Thermo-Grease 04 thermal compound resists changes in consistency temperatures up to 180°C; function as heat transfer media, durable dielectric insulation, barrier against environmental contaminants and as a stress-relieving shock and vibration absorbed over a wide temperature and humidity range.

Typical Properties
Components	0
Mix Ratio
Working Life @ 25°C
Particle Size
Shelf Life	2 years
Cure Type
Potential Uses
Thermal coupler for any heat sink device temperature sensors, power transistors, thermal joints, for any device where efficient cooling is required.
Physical Properties
Appearance	Off White
Filler	Zinc Oxide
Bleed % 24 Hours	0
Viscosity	Paste
Substrates
Density @ 25°C
Specific Gravity @ 25°C	2.46
Press Flow @ 42.5 PSI, @ 25°C	15
Hardness
Lap Shear Strength
Evaporation 24 hrs @ 25°C, %	0
Electrical Properties
Volume Resistivity	2.9 E+14 ohm. cm
Dielectric Constant	4.4
Dielectric Strength	390
Thermal Properties
Operating Temp	-40 to 190°C
Glass Transition Temp (Tg)
Thermal Expansion Coefficient, per °C
Thermal Conductivity W/M-K	0.9
